High Energy Physics
Microchannel plate photomultiplier tube
45 mm dia., MCP-PMT, Multialkali photocathode (Effective area :11 mm dia./Spectral response : 160 nm to 850 nm)
We also have an life improvement type H15547-07. (Datasheet)
|Tube Size||Dia.45 mm|
|Photocathode Area Shape||Round|
|Photocathode Area Size||Dia.11 mm|
|Wavelength (Short)||160 nm|
|Wavelength (Long)||850 nm|
|Wavelength (Peak)||430 nm|
|Spectral Response Curve Code||500S|
|Window Material||Silica glass|
|[Max. Rating] Anode to Cathode Voltage||-3400 V|
|[Max. Rating] Average Anode Current|
|Anode to Cathode Supply Voltage||-3000 V|
|[Cathode] Luminous Sensitivity Min.||100 μA/lm|
|[Cathode] Luminous Sensitivity Typ.||180 μA/lm|
|[Cathode] Radiant Sensitivity Typ.||70 μA/W|
|[Anode] Luminous Sensitivity Typ.||54 A/lm|
|[Anode] Gain Typ.||3.0 x 105|
|[Anode] Dark Current (after 30min.) Max.|
|[Time Response] Rise Time Typ.||160 ps|
|[Time Response] Transit Time Typ.|
|[Time Response] Transit Time Spread Typ.||25 ps|
