High Energy Physics
25mm dia., Head-on type, Bialkali photocathode (Effective area : 22 mm dia./Spectral response : 300 to 650 nm), For scintillation counting
|Tube Size||Dia.25 mm|
|Photocathode Area Shape||Round|
|Photocathode Area Size||Dia.22 mm|
|Wavelength (Short)||300 nm|
|Wavelength (Long)||650 nm|
|Wavelength (Peak)||420 nm|
|Spectral Response Curve Code||400K|
|Window Material||Borosilicate glass|
|[Max. Rating] Anode to Cathode Voltage||1500 V|
|[Max. Rating] Average Anode Current||0.1 mA|
|Anode to Cathode Supply Voltage||1000 V|
|[Cathode] Luminous Sensitivity Min.||70 μA/lm|
|[Cathode] Luminous Sensitivity Typ.||95 μA/lm|
|[Cathode] Blue Sensitivity Index (CS 5-58) Typ.||11|
|[Cathode] Radiant Sensitivity Typ.||88 mA/W|
|[Anode] Luminous Sensitivity Min.||50 A/lm|
|[Anode] Luminous Sensitivity Typ.||250 A/lm|
|[Anode] Radiant Sensitivity Typ.||2.3 x 105 A/W|
|[Anode] Gain Typ.||2.6 x 106|
|[Anode] Dark Current (after 30min.) Typ.||2 nA|
|[Anode] Dark Current (after 30min.) Max.||15 nA|
|[Time Response] Rise Time Typ.||2.5 ns|
|[Time Response] Transit Time Typ.||28 ns|
|[Time Response] Transit Time Spread Typ.||1.2 ns|
|[Anode] Pulse Linearity (2% deviation)||5 mA|
|[Anode] Pulse Linearity (5% deviation)||8 mA|
